VEVOR 3/16 in T316 Stainless Steel Wire Rope, 1000 ft: specs and uses

This is a 1000-foot reel of 3/16 inch stainless steel wire rope from VEVOR. It is sold as cable for railing systems, garden fencing, plant supports, string lights and clotheslines, and because it comes in one long length you can cut it to whatever each job needs. It is raw cable, so fittings, tensioners and posts are bought separately.

What T316 stainless steel means

Stainless steel grade 316 contains molybdenum, which typically improves resistance to corrosion compared with the more common grade 304. That is why 316 is often chosen for outdoor use, near pools and in coastal air. VEVOR says the rope resists wear, rust and corrosion. Even so, stainless can show surface staining over time in harsh conditions, and an occasional wipe-down helps.

What 1x19 construction means

Wire rope is described by the number of strands and the number of wires in each strand. The listing calls this a 1x19 construction: a single group of 19 wires laid together. A 1x19 rope is stiffer and stretches less than more flexible ropes such as 7x7 or 7x19. That makes it a common choice for straight, taut runs like cable railing, where the cable should not sag. The trade-off is that it does not bend around small pulleys well, so it is not meant for hoisting or for tight curves.

Size, length and strength

The rope is 3/16 inch (about 4.8 mm) in diameter and 1000 ft (about 305 m) long, and the reel weighs 73.9 lb (about 33.5 kg). VEVOR states a breaking strength of up to 4,200 lb in its feature list, while the product title quotes 4,700 lb. Since the two figures differ, confirm the strength figure in the product documentation before relying on it. Breaking strength is the load at which the rope fails, not a working load; working loads are set far below it, with a safety factor.

Finish and handling

VEVOR describes the surface as smooth and highly polished, with no burrs, and says it can be cut to any length. Cutting stainless rope cleanly usually takes a proper cable cutter, and taping the area before the cut helps stop the ends from fraying.

Typical uses

• Garden fencing and trellis wires.
• Supports for climbing plants.
• Stair handrails and deck or balcony railing runs.
• String lights and clotheslines.
• General hanging and strapping jobs indoors and out.

VEVOR also calls it an aircraft-style deck railing cable. A complete railing needs end fittings, tensioners, intermediate posts and correct cable spacing, and these must comply with local building codes.

Who it suits

It suits DIYers, gardeners and builders who want a long length of stainless cable they can cut up for several projects, or one large job that needs a lot of cable.

What to check before you buy

• Length needed: add up every run plus extra for fittings and tensioning.
• Fittings: check that swages, turnbuckles and fittings are matched to 3/16 inch rope.
• Codes: railings and guards are regulated, so check local requirements for post spacing, cable spacing and loads, and follow the manual.
• Rated strength: confirm the breaking strength given in the documentation.
• Handling: a 74 lb reel is heavy, and cut ends can be sharp, so wear gloves.
• Not for lifting: don't use cable for overhead hoisting unless it is rated for that.

The short version

• 1000 ft of 3/16 inch (4.8 mm) T316 stainless steel wire rope.
• 1x19 construction: stiff and low-stretch, suited to straight, taut runs.
• Sold for railings, fencing, plant supports, string lights and clotheslines.
• Breaking strength is quoted differently in the title and features, so check it.
• Fittings and tensioners are bought separately; follow local codes for railings.
