Audiopipe APCD4085 Compression Driver: what it is and what to check

The Audiopipe APCD4085 is a resin film compression driver, rated by the brand at 1800 watts. It is a component for car audio systems, where it produces the high frequencies, the part of the sound that carries vocals, cymbals and detail. The listing gives few specifications, so this page explains what this type of part does and what you would want to confirm before choosing one.

What a compression driver is

A compression driver is the sound-producing engine of a horn speaker. Instead of a large cone moving air directly, a small diaphragm vibrates behind a narrow channel, and the sound is compressed into a horn that shapes and projects it. This design is typically very efficient, which is why it is used for high frequencies in loud systems, from car audio to public-address setups.

A driver on its own makes little useful sound. It needs a horn, and in most systems a crossover that sends it only the high frequencies it is meant to handle.

What resin film means

The listing calls the diaphragm "resin film". Diaphragms for compression drivers are commonly made from films such as titanium, polyimide or resin-based materials. In general, a film diaphragm is light and stiff, which helps it respond quickly to the signal. Audiopipe does not give further details in the listing, such as the film's exact composition, thickness or voice coil size.

Reading the 1800 watt figure

Audiopipe describes the driver as an 1800 watt part. Power figures on car audio components vary in meaning. A peak number is usually much higher than the power a driver can handle continuously, and manufacturers use different test methods. The listing does not say which kind of figure this is, so check the manual or the brand's own documentation for continuous (RMS) power before matching an amplifier.

Where it fits in a system

The listing places it among car audio speakers. A typical use is as the high-frequency element in a larger system with separate woofers or subwoofers handling the lower range. Because a compression driver is sensitive and loud, it is often used in systems built for volume, and it usually needs a crossover so low frequencies do not reach it.

Who it suits

It suits people who are building or upgrading a car audio system and already understand how horns, crossovers and amplifiers fit together. If you want a ready-made speaker that bolts in and plays, a complete component or coaxial set may be simpler than a separate driver.

What to check before you buy

• Horn: confirm what horn the driver is meant to mount on, and whether the thread or bolt pattern matches.
• Impedance and power: the listing does not give impedance or power type, so confirm both with the brand before wiring.
• Amplifier: match the amplifier's output to the continuous power, not the peak figure.
• Crossover: plan a high-pass filter so the driver only receives the frequencies it is designed for.
• Space and mounting: check dimensions, which the listing does not state, against where it will go in the vehicle.
• What's included: confirm whether a horn, cables or mounting parts come in the box.

The short version

• A resin film compression driver from Audiopipe, model APCD4085.
• Rated by the brand at 1800 watts; the kind of power figure is not stated.
• Used for high frequencies, normally with a horn and a crossover.
• Few specifications are given, so confirm impedance, size and mounting before buying.
