VEVOR Twin Murphy Bed Kit (YFVTW245): features, specs and who it suits

The VEVOR YFVTW245 is a do-it-yourself Murphy bed kit: the steel frame, pivot hardware and gas struts that let a bed fold up into a wall cabinet. It is aimed at guest rooms, home offices and other small spaces where a bed is needed only some of the time. You supply the cabinet and the mattress platform; the kit supplies the mechanism.

What a Murphy bed kit includes

A Murphy bed, or wall bed, is a mattress and frame that pivots on a hinge and stands upright against a wall. Kits like this one contain the mechanical parts only, which is why the product is filed under bed parts. The cabinet, the bed deck and the finish are typically built separately from plywood or similar material, following the maker's instructions.

Vertical orientation and mattress size

VEVOR describes this as a vertical, or upright, flip: the bed folds with its head end against the wall and the mattress standing on its short edge. This suits rooms with decent ceiling height and a clear wall. The kit dimensions are given as 81 x 46.25 x 82 inches (about 206 x 117 x 208 cm).

VEVOR says it suits mattresses of 75 x 39 inches with a thickness of 6 to 10 inches, which is a standard twin mattress. The same text also uses the word "queen" in one place, so confirm the mattress size against the dimensions and the manual before buying anything else for the project.

Gas struts and how the bed moves

The lifting work is done by gas struts, the same sealed, pressurised pistons used to hold up hatchbacks and office chair seats. They counterbalance the weight of the bed so it can be raised and lowered with modest effort. VEVOR says operation is smooth and quiet, and that the mechanism stays stable after 50,000 open-and-close cycles. That is a brand figure rather than an independent one.

Gas struts are matched to a particular load, so the weight of the mattress and deck matters. A heavier build than the kit expects can make the bed hard to lift or reluctant to stay up.

Frame, finish and legs

The frame is carbon steel with a black coated finish. VEVOR says the coating is waterproof and rust-resistant and that the welds are seamless. The legs are described as thick square tube, intended to support the frame and avoid marking the floor. The kit weighs about 14.8 lb (6.7 kg), so most of the finished bed's weight comes from the wood and mattress you add.

Installation

VEVOR highlights an integrated pivot board that removes the need for manual measuring and clip-style fittings, which it says reduces the risk of misalignment. Even so, a wall bed is a heavy object that swings. Follow the manual closely, anchor the cabinet as instructed and in line with local building codes, and consider professional help if you are not confident.

Who it suits

It suits people who are comfortable with basic carpentry and want to design their own cabinet, for example to match existing built-ins. It is less suited to anyone wanting a finished piece of furniture delivered ready to use.

What to check before you buy

• Mattress size and thickness: match them to the 75 x 39 inch, 6 to 10 inch range.
• Space: allow for the 81 x 46.25 x 82 inch footprint plus clearance for the bed to swing.
• Ceiling height and wall: confirm there is enough height and a wall that can take the anchoring.
• Load limit: the text mentions a figure of 44 lb, which is low for a bed, so check the weight limits and strut specification in the manual.
• Materials and tools: plan the cabinet wood, fasteners and tools separately.
• What's in the box: check the parts list against the manual.

The short version

• A DIY vertical Murphy bed mechanism kit, model YFVTW245, from VEVOR.
• Carbon steel frame with a black coating, gas struts and a pivot board.
• Intended for 75 x 39 inch mattresses, 6 to 10 inches thick.
• Rated by VEVOR for 50,000 open-and-close cycles.
• Hardware only: the cabinet and bed deck are for you to build.
